Windows 5 Frequency 10 Channel Far Field Eddy Current Meter

Windows 5 Frequency 10 Channel Far Field Eddy Current Meter

Windows 5 Frequency 10 Channel Far Field Eddy Current Meter

Brand Name: Suzhou Desisen (DSS) Electronics
Model Number: DMD-559Win
MOQ: 1 set
Price: personnally dicuss
Payment Terms: L/C,D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability: 100 sets
Detail Information
Product Description
Detail Information
Place of Origin:
China
Certification:
ISO 9001, CE
Advanced:
Using The Most Advanced Computer Digital Technology, Far Field Eddy Current Technology And Multiple Mixing Technology
Powerful Function:
The Detection Signals Of Eight Conventional Vortex Channels And Two Far-field Vortex Channels Are Obtained And Displayed On The Same Screen.
Use One Machine For Two Purposes:
Two Probes Can Be Connected At The Same Time To Realize The Flaw Detection And Thickness Detection At The Same Time Or Separately, And One Machine Is Used As Two Machines
Display Mode:
Point/line/blanking
High-pass Filter:
0~500 Hz
Low-pass Filter:
10-10000Hz
Digital Filter Points:
1-100
Frequency Range:
1Hz ~ 6MHz (remote Field Frequency: 5Hz～5KHz);
Gain:
0～90dB, Step Size 0.5dB
Phase Rotation:
0~360°, Step 1°
Operating Temperature:
-15~55℃
Storage Temperature:
-20~60℃
Relative Humidity:
Not Exceeding 85%
Operating Voltage:
DC24V
Packaging Details:
wooden case
Supply Ability:
100 sets
Highlight:

Win Five Eddy Current Meter

,

Ten Channel Eddy Current Meter

,

Far Field Eddy Current Meter

Product Description

Product Description:

It adopts a Windows-based graphical operation interface, the most advanced computer digital technology, remote field eddy current technology, and multiple mixing technology; it can obtain and display the detection signal graphs of eight conventional eddy current channels and two remote field eddy current channels on the same screen at one time.

Features:

Five independent selectable frequencies, frequency range: 1Hz~6MHz; three real-time mixing units, multiple display modes optional (eight-trace impedance plan view/sixteen strip curves/three-dimensional C-scan eddy current imaging); simultaneous differential and absolute eddy current testing, completing flaw detection and thickness measurement in one step; possessing all functions, instrument characteristics, and application scope of DMD-556Win.



Technical Parameters:

  1. Ten independent detection channels

2. Twelve hardware alarm output interfaces

3. Fast analog/digital electronic balancing

4. Automatic/manual amplitude and phase measurement

5. Original non-equal-amplitude phase/amplitude alarm

6. Multi-frequency detection configuration analysis function

7. Probe excitation amplitude adjustable via keyboard

8. Massive storage of independent detection programs and inspection data

9. Display of four impedance plane graphs and six strip-type time-base scanning curves

10. Scalable C-scan display function

11. Background selection between Cartesian coordinate system and polar coordinate system

12. Capable of connecting two types of probes simultaneously to complete flaw detection and thickness measurement at the same time or perform separate flaw detection, making one machine serve as two

13. Industrial control computer type or laptop type optional, with high-speed USB2.0 communication connection mode between the main unit and laptop

14. Equipped with remote field detection function

15. Both a complete remote field eddy current detection system and possessing the advanced performance of conventional multi-frequency, multi-channel eddy current detection instruments.


Support and Services:

Technical Support and Service for Portable Eddy Current Meter

We provide technical support and service to ensure our customers are satisfied with their Portable Eddy Current Flaw Detector. We offer both on-site and online support for all of our products.

On-site Support

Our on-site support team is available to help with any installation, troubleshooting, or maintenance related issues you may have with your Portable Eddy Current Flaw Detector. Our technicians can come to your location and help with any questions or problems you may have.

Online Support

Our online support team is available 24/7 to help with any questions or issues you may have with your Portable Eddy Current Flaw Detector. We have a live chat feature on our website, as well as an online ticket system for more in-depth issues. Our team is always available to help.



FAQ:

Q1: What is the brand name of this product?

A1: The brand name of this product is Desisen.

Q2: What is the model number of this product?

A2: The model number of this product is DMD-559Win

Q3: Where is this product made?

A3: This product is made in China.

Q4: Does this product have any certification?

A4: Yes, this product has ISO9001 certification.

Q5: What's the minimum order quantity?

A5: The minimum order quantity is 1.
