Digital Far Field Microprocessor Portable Eddy Current Flaw Detector
Contact me for free samples and coupons.
WhatsApp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xProduct Details
| Advanced | T Adopts The Most Advanced DSP And FPGA Digital Electronic Technology, Far-field Eddy Current Technology And Microprocessor Technology | Good Performance | With Multi-frequency, Eddy Current Detection Instrument Advanced Performance, Especially With High Sampling Rate And Ultra-low Noise And High Signal-to-noise Ratio |
|---|---|---|---|
| Wide Detection Range | Used To Detect A Variety Of Metal Parts Testing Equipment Including Signal Power Source, Signal Measurement, Signal Recording And Processing, Made Into A Tube Can Pass The Form | Built-in Lithium Battery | A Full Charge Lasts 6-8 Hours |
| Highlight | Digital Eddy Current Flaw Detector,Microprocessor Eddy Current Flaw Detector,Portable Eddy Current Flaw Detector |
||
Product Description
Product Description:
Features:
Technical Parameters:
| Name | Portable Eddy Current Flaw Detector FET-9HS |
|---|---|
| Frequency range | 1 Hz ~ 20 MHz (far field frequency 1Hz ~ 20KHz); |
| Gain | 0 ~ 90dB, step 0.5dB |
| Phase rotation | 0 ~ 359° step 1 ° |
| Gain ratio (Y/X) | 0.1 ~ 10 |
| Gain/Phase Measurement | manual/automatic |
| Display Mode | Dot/Line/Fade |
| High-pass Filter | Off, 0 ~2000Hz |
| Low Pass Filter | Off, 10~2000kHz |
| Display | Semi-reflective LCD with backlight, suitable for long term observation in darkness or direct sunlight |
| scanning | erase, refresh and retain three scanning modes |
| filter | digital and analogue filter |
| Operating Temperature | -15~55℃ |
| Storage Temperature | -20~60℃ |
| Relative Humidity | not more than 85% |
| Operating Voltage | AC220±10V |
| With probe automatic zero system | |
| fast mode digital / proposed electronic balance | |
| automatic (manual) eddy current signal amplitude, phase measurement, eddy current signal slow (adjustable) expansion of playback | |
| time base scanning and impedance plane map on the same screen | |
| with the configuration of the analysis function | |
| with a unique non-equal amplitude phase / amplitude alarm domain | |
| the hardware alarm output port | |
| can be stored in a variety of massive testing procedures and test data | |
| automatic Amplitude, phase / defect depth curve display | |
| right-angle coordinate system and polar coordinate system background selection | |
| comes with lithium batteries (fully charged can be used for 6-8 hours) | |
| the number of points of digital filtering: 1 ~ 100 | |
| the hardware alarm output | |
| the alarm output signal |
Support and Services:
Technical Support and Service for Portable Eddy Current Flaw Detector
We provide technical support and service to ensure our customers are satisfied with their Portable Eddy Current Flaw Detector. We offer both on-site and online support for all of our products.
On-site Support
Our on-site support team is available to help with any installation, troubleshooting, or maintenance related issues you may have with your Portable Eddy Current Flaw Detector. Our technicians can come to your location and help with any questions or problems you may have.
Online Support
Our online support team is available 24/7 to help with any questions or issues you may have with your Portable Eddy Current Flaw Detector. We have a live chat feature on our website, as well as an online ticket system for more in-depth issues. Our team is always available to help.
FAQ:
Q1: What is the brand name of this product?
A1: The brand name of this product is Desisen.
Q2: What is the model number of this product?
A2: The model number of this product is 598.
Q3: Where is this product made?
A3: This product is made in China.
Q4: Does this product have any certification?
A4: Yes, this product has ISO9001 certification.
Q5: What's the minimum order quantity?
A5: The minimum order quantity is 1.
