Digital Rotary Flaw Detection Equipment Steel Wire Dn Line Production Side Detector

Name: Digital Rotary Flaw Detection Equipment Steel Wire Dn Line Production Side Detector
Brand: Suzhou Desisen(DSS) Electronics Co.,Ltd
SKU: DSS-ET-99
Availability: InStock

Brand Name:	Suzhou Desisen (DSS) Electronics
Model Number:	DSS-ET-99
MOQ:	1 set
Price:	consult
Supply Ability:	100 SET/ month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO 9001, CE

Speed:

Less Than 50M/MIN

Diameter:

5-7MM

Material:

Steel Wire

Detection Method:

On-line Production Side Detection

Supply Ability:

100 SET/ month

Highlight:

Digital Rotary Flaw Detection Equipment

Rotary Flaw Detection Equipment

Rotary eddy current flaw detector

Product Description

DSS-ET-99 digital rotary flaw detection equipment steel wire Dn-line production side detection,

1,Using rotary probe + through probe

2, frequency range :64Hz-2MHz;

3, gain :0-48db, step is 0.5db

4, phase: 0-360 degrees, step is 1 degree

5, independent optional frequency

6, a variety of different styles of mode Settings

7, automatic phase, amplitude analysis function

8. Automatic zero check system: the zero check interval can be set

9, different styles of alarm area Settings, can be applied to a variety of modes

10, gain ratio (Y/X) : 0.1-10

11, automatic screen clearing/tracking impedance display.

12, with the detection signal playback, access, and other functions
13, fast analog/digital electronic automatic balancing and dynamic tracking filtering
14, the operation interface is simple and intelligent, easy to operate
15, suitable for a variety of probes: such as external through type, rotary type, placed type, etc
16, suitable for all kinds of metal materials wire, bar production factory online quality inspection
17. Quick numbers
18, non-constant amplitude, asymmetric phase alarm area setting
19, a variety of display: impedance, time base
20, digital filtering
21, sound and light alarm output
22, automatic balance time
23. Select internal and external clocks
24, can store a large number of various detection programs and detection data
25, rectangular coordinate system and polar coordinate system background selection
26. Measure the amplitude, phase and digital value of the defect
27, display mode: solid line, disappear
28, blanking display coefficient: 1 ~ 100
